Card Product |
|
Quadhead2Go连接卡 |
|
Part Number |
Q2G-DP4K-C |
Q2G-H4K-C |
|
Form Factor |
PCIe® x16 mechanical, x1 electrical (power only) |
PCIe® x16 mechanical, x1 electrical (power only) |
|
Connectivity |
|
|
Video Input |
Number of channels:1 |
Number of channels:1 |
|
Formats:Mini DisplayPort 1.2 |
Formats:Mini HDMI |
|
Video Output |
Number of channels:4 |
Number of channels:4 |
|
Formats:Mini HDMI |
Formats:Mini HDMI |
|
Network Connector |
1x RJ45 |
1x RJ45 |
|
Multi-Unit Support |
Yes |
Yes |
|
Performance |
|
Maximum Video Resolutions |
Support for custom resolutions; contact Matrox for details. |
Support for custom resolutions; contact Matrox for details. |
|
Memory |
1 GB |
1 GB |
|
Video Input Resolutions |
3840x2160 @60Hz |
3840x2160 @60Hz |
|
3840x2160 @30Hz |
3840x2160 @30Hz |
|
7680x1080 @60Hz |
7680x1080 @60Hz |
|
7680x1080 @30Hz |
7680x1080 @30Hz |
|
1920x4320 @60Hz |
1920x4320 @60Hz |
|
1920x4320 @30Hz |
1920x4320 @30Hz |
|
Other input resolutions including 8Kx8K are supported. Contact Matrox for more details. |
Other input resolutions including 8Kx8K are supported. Contact Matrox for more details. |
|
Video Output Resolutions |
1920x1080 @60Hz |
1920x1080 @60Hz |
|
1920x1080 @30Hz |
1920x1080 @30Hz |
|
1920x1200 @60Hz |
1920x1200 @60Hz |
|
1920x1200 @30Hz |
1920x1200 @30Hz |
|
Other output resolutions are supported. |
Other output resolutions are supported. |
|
Contact Matrox for more details. |
Contact Matrox for more details. |
|
Color Space and Chroma Sub-Sampling |
Input: |
Input: |
|
RGB: 8:8:8 (24 bits per pixel) |
RGB: 8:8:8 (24 bits per pixel) |
|
YUV: 4:4:4, 4:2:2 (8 bits per component) |
YUV: 4:4:4, 4:2:2, 4:2:0 (8 bits per component) |
|
Output: |
Output: |
|
RGB: 8:8:8 (24 bits per pixel) |
RGB: 8:8:8 (24 bits per pixel) |
|
Video and Audio Processing |
|
Supported Configurations |
2x2 (default), 4x1, 3x1, 2x1, 1x2, 1x3, 1x4 in both landscape and portrait modes and other non-rectangular/artistic configurations |
2x2 (default), 4x1, 3x1, 2x1, 1x2, 1x3, 1x4 in both landscape and portrait modes and other non-rectangular/artistic configurations |
|
Non-Rectangular/Artistic Video Walls |
Yes |
Yes |
|
Clone Mode |
Yes |
Yes |
|
Rotation (output) |
Yes. Support for 90, 180, 270 degrees |
Yes. Support for 90, 180, 270 degrees |
|
Bezel Management |
Yes |
Yes |
|
Video Scaling |
Yes |
Yes |
|
Video Cropping |
Yes |
Yes |
|
Stretched Desktop Support |
Yes |
Yes |
|
HDCP Support |
Yes |
Yes |
|
Audio Output Format |
AAC, PCM, Stereo, and Mono |
AAC, PCM, Stereo, and Mono |
|
Audio Sampling Frequency |
44.1 KHz and 48 KHz |
44.1 KHz and 48 KHz |
|
16-bit stereo |
16-bit stereo |
|
Network |
|
Network Standard |
10/100/1000 Base-T Ethernet |
10/100/1000 Base-T Ethernet |
|
Auto-detect |
Auto-detect |
|
Half/full duplex |
Half/full duplex |
|
Command and Control |
Firmware update (via network interface) |
Firmware update (via network interface) |
|
HTTP/HTTPS |
HTTP/HTTPS |
|
mDNS and DNS-SD (discovery) |
mDNS and DNS-SD (discovery) |
|
UPnP (discovery) |
UPnP (discovery) |
|
Physical |
|
Product Dimensions |
0.85 (W) x 5.00 (H) x 6.21 (D) inches |
0.85 (W) x 5.00 (H) x 6.21 (D) inches |
|
2.16 (W) x 12.70 (H) x 15.77 (D) cm |
2.16 (W) x 12.70 (H) x 15.77 (D) cm |
|
Unit Weight |
0.375 lbs / 170 g |
0.375 lbs / 170 g |
|
Cooling |
Fanless |
Fanless |
|
Hardware & Software |
|
Accessories (sold separately) |
Secure Cable Solution (SK-SNLB-6) |
Secure Cable Solution (SK-SNLB-6) |
|
Software |
Matrox PowerWall (free download) |
Matrox PowerWall (free download) |
|
See Matrox PowerWall datasheet for more details. |
See Matrox PowerWall datasheet for more details. |
|
Environmental |
|
Operating Conditions |
Temperature: 0 to 45 degrees Celsius |
Temperature: 0 to 45 degrees Celsius |
|
Humidity: 20% to 80% non-condensing |
Humidity: 20% to 80% non-condensing |
|
Storage Conditions |
Temperature: -40 to 70 degrees Celsius |
Temperature: -40 to 70 degrees Celsius |
|
Humidity: 5% to 95% non-condensing |
Humidity: 5% to 95% non-condensing |
|
Power Consumption |
15W |
15W |
|
General |
|
EMC/EMI Device Class |
Class A |
Class A |
|
EMC/EMI Compliance |
CE (EU) |
CE (EU) |
|
FCC (US) |
FCC (US) |
|
ICES-3 (Canada) |
ICES-3 (Canada) |
|
KC (Korea) |
KC (Korea) |
|
Environmental Compliance |
China RoHS |
China RoHS |
|
EU RoHS |
EU RoHS |
|
REACH |
REACH |
|
Warranty |
Three-year limited warranty with free telephone support |
Three-year limited warranty with free telephone support |
